Baincut CMC Semi Auto
Medium Semi Auto – Carbide Rod Cutter
Solid Welded Steel Construction with Floor Model
-
Sturdy Floor Model Carbide and HSS rod Cutter
Cutting Capacity 3mm to 25mm ( 1”) dia
3 HP (2.2 k.w), 3 Phase Motor
Spindle speed 2800 rpm , Spindle dia 31.75mm(25.4mm optional)
Diamond Wheel dia 8” (200 mm) / 10” ( 250 mm)
Cutting Action: Automatic with Electronic Motor System for ‘Z’ Movement of Cutting Wheel
Easy Flow Cutting Chamber with Special floor coating
Work Holding V-block with Brass Insert, Pneumatic Clamping, and Adjustable Pressure System
-
Manual Adjustable Measuring System with Stopper for Carbide rod from 20 mm to 300mm length
Cut off Wheel Cooling by two additional coolant jets
Inbuilt Movable Recirculation Coolant Tank with 50-Liter Capacity, Equipped with Two-Stage Filtration: 50-Micron and 5-Micron Filter Bag Facility.
0.18 Kw Coolant Recirculation Pump
Voltage: 415V/50 Hz (R+Y+B+N+E)/ (Optional Voltage 220V / 60Hz / 3 Phase / R+Y+B +PE)
Machine Size: 800mm x 850mm x 1400mm ( LxDxH)
Weight Approx.220 kg
Machine Color: Enclosures RAL 7040, Base and Stand RAL 7016
