Baincut CMC
Small carbide tool grinding machine
Solid Welded Steel Construction with Floor Model
-
Sturdy Floor Model Carbide and HSS rod Grinder
3 HP (2.2 k.w), 3 Phase Motor
Spindle speed 2800 rpm , Spindle dia 31.75mm(25.4mm optional)
Easy Flow grinding Chamber with Special floor coating
Work Holding V-block with Brass Insert, Pneumatic Clamping, and Adjustable Pressure System
Manual Adjustable Measuring System with Stopper for Carbide rod from 20 mm to 300mm length
- Inbuilt Movable Recirculation Coolant Tank with 50-Liter Capacity, Equipped with Two-Stage Filtration: 50-Micron and 5-Micron Filter Bag Facility.
-
Cooling by two high flow Coolant system for grinding zone
Cooling by two additional coolant jets
0.18 Kw Coolant Recirculation Pump
Voltage: 415V/50 Hz (R+Y+B+N+E)/ (Optional Voltage 220V / 60Hz / 3 Phase / R+Y+B +PE)
Machine Size: 800mm x 850mm x 1400mm ( LxDxH)
Weight Approx.220 kg
Machine Color: Enclosures RAL 7040, Base and Stand RAL 7016
Safety systems according to CE Compliances
