Description
Product Description
With infinity corrected optical system for examination of mounted metallurgical specimens or for routine quality inspections. Trinocular Inverted Metallurgical Microscope with plan optics and incident light illumination with infinity corrected optical design fully Japanese.
| Objectives | Plan EPI – 5X, Plan EPI – 10X, Plan EPI – 20X, Plan EPI – 50X |
| Eyepieces | Super Wide field WF-10X Eye Pieces , F.N. 22 standard |
| Magnification Range | 100X – 500X (Standard) |
| Mechanical Stage | Co-axial mechanical square stage Size: 191mm x 126mm |
| Magnification Changer | Quintuple, nosepiece with positive precision click stops. |
| Observation Tube | Trinocular head with sliding beam splitter equipped with 30* inclined observation tubes and adjustable interpupillary distance |
| Illumination | Built in Vertical Koehler,s incident illuminator with 6V 30W halogen automatic voltage sensing power supply |
| Focusing | Low positioned, coaxial Coarse and fine focus knobs with adjustable tension control |
| Full Stroke | Fine focusing range :0.2mm per revolution |
| Camera Adopter | C-mount Lens adapter |
